High Temperature Atmosphere Vacuum Furnace for Heat Treatment
Atmosphere vacuum furnace    View:28    Date:2022/04/21

https://www.youtube.com/embed/uAWlOv-1RC0

Product Description:

The furnace facilitate operation of firing cycles where atmosphere condition can be altered during operation cycle, from oxidizing,

(such as air to inert atmosphere), or argon/nitrogen to rough vacuum.This type of furnace makes multi-atmosphere process in one

cycle possible: binder burn out in air and parts sintering under vacuum or inert gas atmosphere.These furnaces are designed for

accurate air/ inert gas flow rate control, accurate temperature control, excellent temperature uniformity, long lasting performance

and safe operations. It is ideal for laboratories and small scale production.

Atmophere Vacuum Furnace

Technical Specification:

Furnace Structure

Double shell steel case with cooling fan to keep outside case cool

High purity foamed ceramic insulation for max. energy saving

Voltage

AC 208-240V, 50/60HZ, Single Phase

Power

15 Kw

Max. Temperature

1650℃

Chamber Size

Depth 400mm × Width 330mm × Height 300mmCustomized

Temperature Control

30 segments easy use PID programmable temperature controller

Control accuracy

+/-1°C

Heating Element

MoSi2 Heating Elements

Thermocouple

B Type

Special Configuration

Explosion Door

Pirani Gauge

We can provide design according to your requirements. Welcome to consult us for more information.

The Customers Feedback:

We have been engaged in heat treatment equipment for more than ten years, and have been committed to providing customers

with solutions to meet their needs and being a solver of customer problems. Thank customers for their affirmation.
